Semi-automatic shock testing machine is also known as pendulum impact testing machine;It is used to measure the impact resistance of metal materials under dynamic load, so as to judge the resistance of materials under dynamic load.The device is equipped with automatic control, compact structure and simple operation.The maximum impact energy of the equipment is 500J, 300J, and equipped with 250J and 150J pendulum.It is mainly used to test the black metal, especially steel and alloy.

GB/ t3038-2002 test of pendulum impact testing machine

GB/T229 -- 2007 metal charpy notch impact test method

GB/ t18658-2002: test sample of charpy v-notch for pendulum impact testing machine

GB/ t2975-1998 test sampling location and sample preparation for mechanical properties of steel and steel products

JJG145-2007 "calibration procedure of pendulum test machine"

GB/ t2611-2007 test machine general technical requirements

Control of microcomputer semi-automatic impact testing machine, controlled by PC computer machine, which can realize Yang pendulum to feeding and positioning, the impact to measure - operation - screen display, printing operation of computerization, and can use their residual energy automatic thrust sample after Yang, prepare for the next test, simple operation, high work efficiency.It is especially suitable for the laboratory of continuous impact test and a large number of metallurgical and mechanical manufacturing industries that do impact tests.Computer can calculate and digital display material impact absorption work, pendulum swing Angle and test average.Remote data transmission can also be realized according to user needs.
