The microcomputer control compressive bending machine is mainly used for cement concrete, pipe material, cement products, hollow bricks, refractory materials, construction materials, stone, rubber bearing construction materials such as compressive strength test.It is a necessary equipment for the laboratory of highway, railway, bridge, building, building materials and colleges and universities.This tester is used to conform to JB/T8763-2001 electro-hydraulic type cement pressure testing machine technology conditions, GB/T17671-1999 cement sand on the compressive strength, flexural test standard, adopt double location test space, has used a dual-use, save a space, the advantages of simple operation.

The machine adopts hydraulic loading, electronic measuring force, load digital display, loading speed display, maximum load maintenance, overload protection and power outage data retention.

JB/T8763-2001

1. The microcomputer controlled compression and folding testing machine adopts high precision sensor and digital display instrument, which can store, inspect and print test results.

2. The machine adopts spinning screw to adjust the compression space, which greatly speeds up the test progress.

3. Increase the anti-folding attachment, and can carry out the anti-folding test.

4. The machine needs no debugging, smoothly landing, refueling and receiving electricity can work.

5. The calibration is simple and the user can calibrate according to the instructions.

6. The microcomputer control anti-pressure and folding test machine of cement is controlled by high precision sensor and computer, which can automatically store, inspect and print test report and print the curve.

7. The machine adopts spinning screw to adjust the compression space, which greatly speeds up the test progress.

8. The machine can design the report according to the requirements of the unit.

9. This machine can realize manual and automatic dual control system.

The maximum test force is 300KN (compression) /10kN.

Test force relative error value: less than 1%

Loading rate is 0.3KN/S to 10KN/S (compression), 50N/s (anti folding).

Acceleration error: + 5%

Pressure plate size: 155mm (compression), 80X150mm (anti folding).

Maximum piston stroke: 80mm

Microcomputer control cement compression and bending test machine piston diameter: 130mm (compression), 60mm.

Maximum oil pressure: 25MPa

Rated flow of oil pump: 1.52L/min

Motor power: 0.75kW

Host size: About 820 mm x 450 x 1300mm

Microcomputer control cement compression and bending test machine host weight: about 500Kg.
